Electronic Current-Transformer Type STWA1SEH

Manufacturer:

Ziehl

Manufacturer part number:

S225549

Be the first to review this product

Delivery date: 12 business days

AC Electronic current transormer, adjustable limit AC 2-10 A, transistor-output, LED

116.2 CAD

PRICE BREAKS - Buy More, Save More

Quantity

10+

20+

Price

105 CAD

92.4 CAD

Qty:

+ -

Specifications
Overview
Reviews
Technical Documents
Request For Quote

Products specifications

Brand	ZIEHL
Country of origin	Germany
Frequency Range(Hz)	50/ 60
Overload capacity	100 A / 300 A
Rated impulse voltage(V)	4000
Rated insulation voltage Ui(V)	250
Protection terminals	IP 20
Applied standards	UL/CSA

The STWA1SEH is used where current flow has to be detected, e.g. to report exceeding of a limit, to switch off a machine or just report the current flow.

The STWA1SEH has an integrated electronics with transistor-output. The limit is adjustable 2 - 10 A with a potentiometer. A LED displays the state.

adjustable switching point 2-10 A
built-in LED displays state of the output
isolated transistor-output max. DC 40 V / 40 mA
output van be directly connected to a digital input of a PLC
integrated diode for reverse voltage protection
electrival connection via screwless pluggable terminals
2-wire, no supply voltage required
DIN-rail-mount or with screws
plug-in current transformer (Ø 11 mm)
max. overload 100 A continuously, 300 A max. 10 s.

Write your own review Close Review Form

Product can be reviewed only after purchasing it
Only registered users can write reviews

Review title:

Review text:

Rating:

Bad
Rating 1 Rating 2 Rating 3 Rating 4 Rating 5
Excellent

General Catalog
Data Sheet
Video

Request For Quote

Your name *

Your email *

Inquiry *

Description

The STWA1SEH is used where current flow has to be detected, e.g. to report exceeding of a limit, to switch off a machine or just report the current flow.

The STWA1SEH has an integrated electronics with transistor-output. The limit is adjustable 2 - 10 A with a potentiometer. A LED displays the state.

adjustable switching point 2-10 A
built-in LED displays state of the output
isolated transistor-output max. DC 40 V / 40 mA
output van be directly connected to a digital input of a PLC
integrated diode for reverse voltage protection
electrival connection via screwless pluggable terminals
2-wire, no supply voltage required
DIN-rail-mount or with screws
plug-in current transformer (Ø 11 mm)
max. overload 100 A continuously, 300 A max. 10 s.

Products specifications

Brand	ZIEHL
Country of origin	Germany
Frequency Range(Hz)	50/ 60
Overload capacity	100 A / 300 A
Rated impulse voltage(V)	4000
Rated insulation voltage Ui(V)	250
Protection terminals	IP 20
Applied standards	UL/CSA
